· 10.1-inch 1920×1200 FHD Screen
· Zigbee & Bluetooth Gateway
· Physical Buttons for Device and Scene Control
· Supports Control of All Tuya Ecosystem Devices, Including Groups and Infrared Devices
· Supports Lighting Scenes
· Supports Equipment from Mainstream Video Intercom Manufacturers
· Access Control System with Door Opening Linkage Function
· Supports Intercom with IPC
| Control Panel MAX | |
| Display | 10.1-inch IPS MIPI screen |
| Screen Type | Touch Screen |
| Screen Resolution | 1920 x 1200 |
| Main Chip Model | RK3566 |
| Main Chip Frequenc | 1.8GHz |
| Main Chip Architecture | Quad-core ARM Cortex™-A55 |
| Wi-Fi Type | Upstream 2.4GHz |
| Zigbee Type | Downlink Zigbee |
| Bluetooth Type | Downlink BLE/BLE-mesh |
| RAM | 2GB |
| ROM | 8GB |
| Strong Power Input | 100 ~ 240 VAC( ± 10%), 50/60Hz +-3Hz, neutral wire |
| Weak Current Input | 12V 1A type-C |
| Ethernet | 1*100M RJ45 （EU not included） |
| Camera | 500 million pixels |
| Microphone | 2 Mike |
| Speaker | 2 Speakers / 1.8W |
| Antenna | 3pcs / Built-in shell antenna |
| Operating system | Android 11 |
| OTA | Support |
| Operating Temperature | 0~40℃ |
| Dimensions | 259×161×37mm (including base) |
