– 4-Wire Installation.
– Integrated Linux Operating System.
– Quad-Screen Split View Presentation.
– Video Output Capability.
– Advanced Motion Detection.
– 4-Channel Video Recording with Customizable Schedule Settings.
– Snapshot and Video Recording Functions.
– Compatible with microSD Card (Up to 1TB Capacity).
– Supports Up to 2 Door Stations, 2 CCTV Cameras, and 6 Indoor Monitors.
– Remote Management via the Tuya App.
| System | |
| Operation System | Embedded LINUX OS |
| ROM | 1G |
| RAM | 2G |
| CPU | Embedded ARM Micro Processor MT824 |
| Wi-Fi Connectivity | 2.4GHz |
| Basic | |
| Display | 11.6-inch IPS |
| Screen Type | Capacitive Touchscreen |
| Screen Resolution | 1920 x 1080 |
| Audio Compression | G.711a; G.711u |
| Audio Input | Built-in omnidirectional microphone |
| Audio Output | Built-in speaker |
| Audio Quality | Noise suppression and echo cancellation |
| Audio Mode | Half duplex talk |
| Interface | |
| Door Station Interface | 2 |
| CCTV Camera Interface | 2 |
| Extension Interface | 2 |
| External Lock | 1 |
| Video Output | 1 |
| Network Interface | 1 |
| Power Interface | 1 |
| Storage | MicroSD card,max. 1TB |
| General | |
| Power | 12 VDC/2A; Built-in power supply:AC100-240V (Optional) |
| Power Consumption | Standby≤4.8W,Working≤8W |
| Working Temperature | -20℃ ~ 50℃ |
| Relative Humidity | 20%-95%(RH) |
| Certifications | CE;RED;RoHS |
| Material | ABS plastic |
| Installation | Surface mounting |
| Dimensions | 289mm*187mm*24.5mm |
| Weight | 0.65kg |
| Language | English, Russian, Ukrainian, German, Arabic (customizable) |
